Allied Telesyn AT-VIEW PLUS
VLAN MANAGER
6.14 AT-9800/SwitchBlade Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
6.14.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Type
This indicates the type of the VLAN.
• Port-based
• IP subnet-based
• Protocol-based
• MAC address-based
• Limited protocol-based
Status
This indicates the status of the VLAN.
• dynamic
• static
Note - After Import VLAN operation, Default VLAN with invalid Untagged Ports will have
successful status.
PN 613-50666-00 Rev C Page 56 of 59
