AT-S85 and AT-S97 Management Software Command Line Interface User’s Guide
149
Note the following guidelines when modifying the commands in this
section:
ˆ Each channel must have its own command line.
ˆ If you delete a command, the corresponding channel’s operating mode
will be Link Test, the default value.
ˆ As previously mentioned, the PORTID parameter must specify just the
channel number. Do not include a chassis ID or slot number. The latter
are defined in the header lines of the Blade Configuration section.
The next subsection in a Blade Configuration, shown in Figure 32,
configures the operating parameters of the ports on the media converter
module, both twisted pair and fiber optic. The port operating parameters
are set with a modified version of the SYSTEM SET PORT command,
where the values in the ID parameter are truncated to the channel number
and port letter. For a description of this command, refer to “SYSTEM SET
PORT” on page 87.
Figure 32. Blade Configuration - Port Operating Parameters
Note the following guidelines when modifying the commands in this
section:
ˆ Each port must have its own command line.
ˆ A port can have more than one command line.
ˆ A command line cannot exceed eighty characters.
ˆ If you delete a port’s configuration command from the file, the port
operates with the default settings.
ˆ The ID parameter specifies just the channel number and port letter.
system set port id=1/a ingress-rate-limit=none egress-rate-limit=none
system set port id=1/b duplex=full ingress-rate-limit=none egress-rate-
limit=none
system set port id=2/a speed=100 duplex=full crossover=mdi
system set port id=2/a ingress-rate-limit=128k egress-rate-limit=none
system set port id=2/b duplex=full ingress-rate-limit=none egress-rate-
limit=none
system set port id=3/a ingress-rate-limit=none egress-rate-limit=none
system set port id=3/b duplex=full ingress-rate-limit=none egress-rate-
limit=none
system set port id=4/a speed=10 duplex=full crossover=mdi
system set port id=4/a ingress-rate-limit=none egress-rate-limit=none
system set port id=4/b duplex=full ingress-rate-limit=none egress-rate-
limit=none
