Verifying the Stack
To verify stack operations, perform the following procedure:
1. Establish a local management session on any switch in the stack. For
instructions, refer to “Starting a Local Management Session” on
page 75.
2. From the User Exec mode, enter the SHOW STACK command:
awplus> show stack
The command lists the switches in the stack. An example is show in
Figure 44.
Figure 44. SHOW STACK Command
Here are a couple things to consider:
 The command should list all the switches in the stack. If the list is
incomplete, refer to Chapter 9, “Troubleshooting” on page 111.
 The Operational Status field displays “Normal operations” when
the switches are connected in the ring topology and “Ring topology
is broken” when the switches are connected in the linear topology.
 The priority values will be 128, the default value, if they have not
been changed on the switches.
 Given that there is no relationship between the ID numbers and the
selection of the master switch, the active master in the SHOW
STACK command might not have the ID number 1.
3. Do one of the following:
 If you want to change the priority values of the switches, go to
“Setting the Priority Numbers” on page 96. The procedure is
optional.
awplus> show stack
Virtual Chassis Stacking summary information
ID Pending ID MAC address Priority Status Role
1 - 0015:774f:ed30 128 Ready Active Master
2 - 0015:774f:65ab 128 Ready Member
3 - 0015:774f:d4a7 128 Ready Member
4 - 0015:774f:c431 128 Ready Member
Operational Status Normal operations
Stack MAC address 0015:774f:ed30
awplus(config)#
