Chapter 6: Cabling the Stacking Ports
80
Cabling Switches with AT-StackXS/1.0 Transceivers
To cable the switches of the stack with AT-StackXS/1.0 transceivers,
perform the following procedure:
Warning
A transceiver can be damaged by static electricity. Be sure to
observe all standard electrostatic discharge (ESD) precautions,
such as wearing an antistatic wrist strap, to avoid damaging the
device.
1. Remove the dust plug from the S1 slot on the top switch of the stack,
as shown in Figure 33.
Figure 33. Removing the Dust Plug from the S1 Slot
2. Remove the transceiver from its shipping container and store the
packaging material in a safe location.
3. Remove the dust cap from one end of the transceiver, as shown in
Figure 34 on page 81.
