x510 Series Installation Guide for Virtual Chassis Stacking

17

Supports single-port BiDi 1000Base-LX SFP transceivers

Supports 1000Base-ZX SFP transceivers

Supports 10/100/1000Base-T twisted pair transceivers

Note

SFP transceivers must be purchased separately. For a list of
supported transceivers, contact your Allied Telesis distributor or
reseller.

SFP+ Slots

Here are the basic features of the four SFP+ slots on the switches:

Supports 10Gbps, 10GBase-SR/LR fiber optic transceivers

Supports 10Gbps AT-SP10TW direct connect twinax cables with
SFP+ transceiver-style connectors

Supports 1000Base-SX/LX SFP transceivers

Supports single-port BiDi 1000Base-LX SFP transceivers

Supports 1000Base-ZX SFP transceivers

Note

The SFP+ slots do not support 100Mbps 100Base-FX transceivers.

Note

SFP and SFP+ transceivers must be purchased separately. For a
list of supported transceivers, contact your Allied Telesis distributor
or reseller.

Note

SFP+ slots 27 and 28 on the AT-x510-28GTX and AT-x510-28GPX
Switches and slots 51 and 52 on the AT-x510-52GTX and AT-x510-
52GPX Switches are initially configured as stacking slots for the
VCStack feature. If you intend to use the switch as a stand-alone
unit, you must disable the VCStack feature before using the slots
with standard SFP or SFP+ transceivers. The configuration
instructions are provided in the x510 Series Installation Guide for
Stand-alone Switches
.

Stacking Slots

Two of the SFP+ slots can be used to create a VCStack of up to four
switches. The slots support these stacking transceivers when the switch is
in the stacking mode:

AT-StackXS/1.0 Twisted Pair Transceiver - 1 meter

AT-StackOP/0.3 Fiber Optic Transceiver - 300 meters
