Rj-45 style serial console port pinouts – Allied Telesis x510 Series User Manual
Page 119
x510 Series Installation Guide for Virtual Chassis Stacking
119
RJ-45 Style Serial Console Port Pinouts
Table 21 lists the pin signals of the RJ-45 style serial Console port.
Table 21. RJ-45 Style Serial Console Port Pin Signals
Pin
Signal
1
Looped to pin 8.
2
Looped to pin 7.
3
Transmit Data
4
Ground
5
Ground
6
Receive Data
7
Looped to pin 2.
8
Looped to pin 1.
