Chapter 5: Verifying the Status of VCStack
76
Note
The port settings are for a DEC VT100 or ANSI terminal, or an
equivalent terminal emulator program.
4. Press Enter.
You are prompted for a user name and password.
5. If this is the initial management session of the switch, enter “manager”
as the user name and “friend” as the password. The user name and
password are case sensitive.
The local management session starts when the User Exec mode
prompt, shown in Figure 26. is displayed.
Figure 26. User Exec Mode Prompt
The User Exec mode is the first level in the command mode interface.
For complete information on the modes and commands, refer to the
Software Reference for x510 Series Switches, AlliedWare Plus
Operating System from www.alliedtelesis.com.
Activating
VCStack
To activate the VCStack feature from the local management session,
perform the following procedure:
1. Enter the ENABLE command to move from the User Exec mode to the
Privileged Exec mode, as shown in Figure 27.
Figure 27. Moving to the Privileged Exec Mode with the ENABLE
Command
2. Enter the CONFIGURE TERMINAL command to move to the Global
Configuration mode, as shown in Figure 28.
Figure 28. Moving to the Global Configuration Mode with the CONFIGURE
TERMINAL Command
awplus>
awplus> enable
awplus#
awplus# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
awplus(config)#
