Allied Telesis x510 Series User Manual
Page 82
Chapter 6: Cabling the Stacking Ports
82
Figure 35. Installing the AT-StackXS/1.0 Transceiver in Slot S1
5. Remove the dust cover from the S2 slot in the next switch in the stack
as shown in Figure 36 on page 83.
Note
The cable must crossover to different slots on the switches. The
stack will not work if you connect two S1 or S2 slots together.
Release tab
