Allied Telesis x510 Series User Manual
Page 110
Chapter 8: Cabling the Networking Ports
110
Figure 59. Positioning the SFP or SFP+ Handle in the Upright Position
7. Connect the fiber optic cable to the transceiver, as shown in Figure 60.
The connector on the cable should fit snugly into the port, and the tab
should lock the connector into place.
Figure 60. Connecting a Fiber Optic Cable to an SFP or SFP+ Transceiver
8. Repeat this procedure to install additional transceivers.
SFP Handle
