8
Note the top line, which displays the model number of the
UPS
that is
currently connected . Site
ID
and Location are user configuration items.
The display shows the factory defaults.
Press any key to bring up the Main menu:
---------------------- MAIN MENU ------------------------
Date: Dec-16 '97 Time: 08:39:36
1- UPS Status
2- UPS Control
3- UPS Characteristics
4- Data/Event Logging
5- Call-UPS Settings
6- Paging Setup
7- Measure-UPS Info
?- Help
>
Customize Settings
From the Main menu, you can go to the various menus by pressing the
number associated with each of them. Press 5, then
ENTER
to bring up
the Call-
UPS
Settings menu. Set the date, time, password, location, and
baud rate from this menu. The baud rate should be set at
9600
. The other
menu items can be left alone for now. Note that any changes you make
are displayed when you return to the menu.
Then press
ESC
to return to the Main menu. Type 6 and press
ENTER
for
the Paging Setup menu, where you can change the Site
ID
number from
its default setting. If you will be using the paging capability of Call-
UPS
II
, use this menu to enable and set up paging.
If you plan to use Call-
UPS II
for logging, go to the Main menu, type 4
and press
ENTER
for the Data/Event Logging menu. Proceed from there
to set up logging.
To change any of the changeable setting of the
UPS
and Call-
UPS II
, use
the other menus listed in the Main menu. For a full description of the en-
tire menu scheme, see Section 4.
