2 INSTALLATION
2.1
Panel Cut-Out
Figure 1 – Panel Cut-Out for the RCS
2.2
RCS Optional Mounting Bracket (HE800ACC210)
The optional mounting bracket is used with SmartStack Modules that have connectors located on two
sides. (Note that many SmartStack Modules only have connectors on one side.)
Figure 2 – Optional Mounting Bracket for Use with the RCS.
6.312 (160.32 mm)
1.250
(31.75 mm)
