For more information on the RCS116, refer to the OCS LX Series Hardware Manual (MAN0755).
For more information on the RCS210 / RCS250, refer to the Control Station Hardware Manual
(MAN0227).
1 SPECIFICATIONS
Table 1 – Specifications for RCS116 / 210RCS210 / RCS250
Humidity 5% to 95% non-condensing
Primary Power Range* 10-30VDC
Ladder Execution
Typical Execution Speed
0.7 ms. per 1K of boolean logic.
Ladder Capacity RCS116: 16Kbytes
RCS210: 64Kbytes
RCS250: 128KBytes
CAN Power Range 12 – 25 VDC
CAN Power Current 75mA maximum
Primary Serial
Standard 9 pin RS-232 for programming, monitoring, and network
administration. Modbus/RTU Master, Slave, ASCII Send and Receive,
and CsCAN Serial also supported.
CAN Network CsCAN Network / DeviceNet Slave
Input / Output Local (All Modules): Maximum of four (4) SmartStack Modules per OCS
Remote (OCS110 / 210/ 250 / or RCS250 Modules):
In addition to 4 local I/O modules, up to 20 remote SmartStack I/O
Modules can be connected to an OCS or RCS using five Fiber Optic
Bases, which each contain four I/O slots.
UL
CE Please refer to Compliance Table located at
http://www.heapg.com/Support/compliance .htm
Operating Temperature 0
°
C to +60
°
C
Typical Power Draw * 150mA @ 24VDC
Inrush Current * 1A @ 24VDC for 8mS
Height 7.00” (177.8 mm)
Width 1.75“ (44.45 mm)
Mounting Depth 4.00” (101.60 mm)
Keypad Although the RCS does not have a local operator interface, it supports a
remote operator interface through a PC connected to the RCS unit’s built-
in network. 32-Key (Remote Only)
Display Although the RCS does not have local display, it supports a remote
operator interface through a PC connected to the RCS unit’s built-in
network.
* These specifications are for RCS products without any SmartStack I/O Modules attached. The
specifications for the SmartStack Modules can be found in the applicable SmartStack Data Sheets.
15 JAN 2010 MAN0432-04
Remote Control Station
HE800RCS116 /
HE800RCS210 / RCS250
Products Specifications
and Installation Data
