Red Lion PAXLCR - Manual (Page 5)

4.0 R
EVIEWING THE
F
RONT
B
UTTONS AND
D
ISPLAY
8.8.8.8.8.8
B
A
RST SEL PAR
1 SP 2 SP
BUTTON DISPLAY MODE OPERATION PROGRAMMING MODE OPERATION
PAR Access Programming Mode Store selected parameter and index to next parameter
RST
SEL
Resets count display(s) and/or outputs
Index display through enabled values
OPERATING MODE DISPLAY DESIGNATORS
“A” - Counter A value
“B” - Counter B value (dual count or batch)
- Rate value is displayed with no designator
“SP1” - Indicates setpoint 1 output status.
“SP2” - Indicates setpoint 2 output status.
Pressing the SEL button toggles the meter through the selected displays. If display scroll is enabled, the display will toggle automatically every four seconds between
the enabled display values.
Advance through selection list/select digit position in
parameter value
Increment selected digit of parameter value
5
PROGRAMMING MODE ENTRY (PAR BUTTON)
It is recommended all programming changes be made off line, or before
installation. The meter normally operates in the Display Mode. No parameters
can be programmed in this mode. The Programming Mode is entered by
pressing the
PAR button. If it is not accessible, then it is locked by either a
security code or a hardware lock.
MODULE ENTRY (SEL & PAR BUTTONS)
The Programming Menu is organized into four modules. These modules group
together parameters that are related in function. The display will alternate between
 and the present module. The SEL button is used to select the desired module.
The displayed module is entered by pressing the PAR button.
MODULE MENU (PAR BUTTON)
Each module has a separate module menu (which is shown at the start of each
module discussion). The PAR button is pressed to advance to a particular
parameter to be changed, without changing the programming of preceding
parameters. After completing a module, the display will return to
  .
Programming may continue by accessing additional modules.
SELECTION / VALUE ENTRY
For each parameter, the display alternates between the present parameter and
the selections/value for that parameter. The SEL and RST buttons are used to
move through the selections/values for that parameter. Pressing the PAR button,
stores and activates the displayed selection/value. This also advances the meter to
the next parameter.
For numeric values, the value is displayed with one digit flashing (initially
the right most digit). Pressing the RST button increments the digit by one or the
user can hold the RST button and the digit will automatically scroll. The SEL
button will select the next digit to the left. Pressing the PAR button will enter the
value and move to the next parameter.
PROGRAMMING MODE EXIT (PAR BUTTON)
The Programming Mode is exited by pressing the PAR button with  
displayed. This will commit any stored parameter changes to memory and
return the meter to the Display Mode. (If power loss occurs before returning to
the Display Mode, verify recent parameter changes.)
PROGRAMMING TIPS
It is recommended to start with Module 1 and proceed through each module in
sequence. When programming is complete, it is recommended to record the
parameter programming and lock out parameter programming with the user input
or programming security code.
FACTORY SETTINGS
Factory Settings may be completely restored in Module 3. This is useful
when encountering programming problems.
ALTERNATING SELECTION DISPLAY
In the explanation of the modules, the following dual display with arrows will
appear. This is used to illustrate the display alternating between the parameter
on top and the parameter’s Factory Setting on the bottom. In most cases,
selections and values for the parameter will be listed on the right.
Indicates Program Mode Alternating Display
Factory Settings are shown.
Parameter
Selection/Value




5.0 P
ROGRAMMING THE
M
ETER
Parameters
Output
Setpoint
Parameters
Input Setup
Pro
DISPLAY
MODE
Panel Key
Parameters
3-dSP
Parameters
Display and Front
NO
PAR
SEL
PAR PAR PAR PAR
2-rAtE 1-INP 4-SPt
Rate Setup
OVERVIEW
PROGRAMMING MENU
