Configuring Loggers
28
©
2011 Vaisala Canada Inc
You can use this window to:
• Edit the logger description (see page 31).
• Set the sample timing (see page 33).
• Enable or disable logger channels (see page 39).
• vLog VL: Link loggers to audit trail file (see page 31).
Any changes will only affect the logger currently con-
nected to the COM port.
Understanding the Logger Setup Window
The following table describes the information displayed on
the Logger Setup window:
Table 3: Logger Setup window information
Description
Logger description (For information on configuring the logger
description, see “Configuring Logger Description” on page 31.)
Hardware
Model
Hardware model number of the currently-connected logger
Hardware
Revision
Hardware version number associated with the currently con-
nected logger
Firmware
Version
Firmware version associated with the currently connected logger
Serial Number
Unique eight-character product serial number of the currently-
connected logger. This number should match the serial number
label on the back of the logger.
Logger Status
Indicates the sampling status of the currently-connected logger.
The possible modes are:
• Sampling: The logger is currently taking samples and the
memory is not full.
• Sampling (wrapped): The logger is currently taking samples
with the memory full. The oldest reading is discarded and
replaced with the newest.
