Grooving, Profiling, Face grooving – Sandvik Coromant Parting and grooving - users guide User Manual
Page 56

54
The CoroTurn XS system includes different insert types for a wide range of applications i.e.
grooving, profiling-grooving, face-grooving, pre-parting as well as turning, back-turning and
threading.
Grooving
Grooving widths from 0.78–2 mm are available in different lengths for maximum stability, a
very important feature when grooving.
Profiling
Round insert style for internal profiling and grooving available insert widths from 1–2 mm.
Face grooving
Face grooving inserts are available for hole diameters from 6.2 mm and insert widths
from 1–3 mm. The maximum cutting depth for these inserts is 6 mm.
Grooving
Turning
Threading
