9
C = Cut-off i.e. Parting
G = Grooving
T = Turning
R = Round insert i.e. Profiling
A = Aluminium machining
The first letter in the geometry name repre-
sents different application areas.
F = Finishing i.e. low feed area
M = Medium feed area
R = Roughing i.e. high feed area
O = Optimising i.e. for special areas
S = Sharp edge, extremely low feed area
E = Edge rounded, for special cases
The second letter gives information about
feed area.
N123G2-0300-0002-CM
Code example:
Geometry designation
Geometries
A large variety of geometries are available, dedicated to different applications and feed areas.
Select the geometry after application and feed, see the table.
Parting
(Cut-off) Grooving Turning Profiling
(Round) Aluminium pro-
filing
Finishing CF GF TF
Medium CM GM TM RM AM
Roughing CR
Optimiser RO
Sharp CS RS
ER treated GE RE
CoroCut insert geometries
