10
CoroCut3 – for shallow parting
Intended for economical shallow parting in mass production.
The triangular shaped 3-edged inserts are available in widths 1–2 mm. The insert seat with a
stable triangular shape allows cutting depths up to 6.4 mm.
Inserts
Available in 1, 1.5 and 2 mm widths and two insert seat styles, T for right hand and U for left
hand holders. Depth limitations as below.
Neutral inserts and front angled versions in 5° and 10° available.
Tailor made inserts available from 0.5–3.20 mm.
Geometries
Available in two geometries, CM and CS.
CM chip breaking geometry is intended for normal cutting conditions.
CS geometry with an extra sharp edge together with an open chip former should be used at
very low feeds and in low-carbon materials. CS is also intended for multi-spindle machines.
Right hand style
insert (T)
Left hand style
insert (U)
Insert width,
mm
Max. cutting depth, a
r
, for
CoroCut3 inserts, mm
1.0
4.3
1.5
6.4
2.0
6.4
