50
12 VDC System DEFAULT MINIMUM MAXIMUM
Float Voltage 13.6V 12V 15V
Absorb Voltage 14.4V 13V 16V
EQ Voltage 14.4V 14V 17V
ReFloat 12.5V 11V 13V
LBCO 10.5V 9V 12V
LBCI 12.5V 10V 14V
Sell RE 13V 10V 15V
Gen Alert
Off Set Point 14V 12V 18V
On Set Point 11V 10V 14V
Load Shed Off Set Point 11V 10V 14V
Vent Fan ON Set Point 13V 10V 16V
Diversion ON Set Point 14.6V 12V 16V
Absorb Time 1.0 hours 0.0 hours 24.0 hours
EQ Time 1.0 hours 0.0 hours 24.0 hours
Float Time 1.0 hours 0.0 hours 24.0 hours
AC2/Gen Transfer Delay
(Cycles for AC) 60 cycles*
(*20 for Grid-Tie) 0 cycles 240 cycles
Search 6 0 50
Grid Lower Limit 207V 80V 220V
Grid Upper Limit 270V 250V 300V
Grid Connect Delay .5 min .2 min 15.0 min
DROP or USE USE N/A N/A
Charger OFF/AUTO/ON AUTO
AUX Output Option COOL FAN
Gen Alert ON Delay 4 min 0 min 240 min
Gen Alert OFF Delay 9 min 0 min 240 min
Vent Fan OFF Delay 5 min 0 min 30 min
Gen Window Lower Limit 208V 80V 220V
Gen Upper Window Limit 270V 250V 300V
AC1/Grid Transfer Delay
(Cycles of AC)
6 0 240
Set AUX Control AUTO
Search Pulses 8 2 20
Search Pulse Spacing
(Cycles AC) 60 4 120
Stacking Phase 1 or 2 phase
InPut Select Master Gen
Charge Rates
Vented 24 & 48 VDC 9 AAC 0 AAC 10 AAC
Vented 12 VDC 6 AAC 0 AAC 7 AAC
Sealed 24 & 48 VDC 5 AAC 0 AAC 7 AAC
Sealed 12 VDC 5 AAC 0 AAC 6 AAC
Grid Input Settings
Set AC Input Size 28 Amp 5 Amp 30 Amp
Gen Input Settings 28 2 30
Set VAC 230V 210V 240V
Correction Factor
• 24VDC: Multiply 12VDC values by 2
• 32VDC: Multiply 12VDC values by 2.64
• 48VDC: Multiply 12VDC values by 4
FX Default Values (subject to change with FX upgrades)
