ADV/FX/AUX-------------P00

aux output Remote

function

DOWN INC DEC PORT

From the Remote aux output function screen,

press the soft key. This will bring up

the fi rst of several screen used to adjust which

ever mode you have chosen for the AUX

function.

ADV/FX/AUX---------------P00

genalert 11.5vdc

on set point

DOWN INC DEC PORT

The genalert on set point screen shows the

voltage--whose range is between 10.0VDC and

14.0VDC, adjusted with the and

soft keys--at which the AUX is energized in

genalert mode. Press the soft key to

view the genelert on delay screen.

ADV/FX/AUX---------------P00

genalert 4 minutes

on delay

DOWN INC DEC PORT

The genalert on delay is the amount of time the

battery voltage must remain below the genalert

set point before the AUX is energized. This allows

for brief periods of heavy load usage and has a

range of 0-240 minutes in one minute increments,

adjustable with the and soft keys.

Press the soft key to bring up the

genalert off set point screen.

ADV/FX/AUX---------------P00

genalert 14.0 vdc

off set point

DOWN INC DEC PORT

In genalert mode, the AUX de-energizes when

the genalert off set point is reached. This set

point’s range is between 12.0VDC and 18.0VDC

and is adjusted in 0.1 VDC increments using the

and soft keys. Press the

soft key to view the genalert off delay screen.
