1-2PH MASTER
With the Port 01 FX as the Master, press the soft key to change the remaining Ports and
designate the remaining FXs as Slaves. The MATE screen for Port 02 will look like this:
ADV/FX/STACK---------P02
stack 1-2ph Master
phase
DOWN INC DEC PORT
• The MATE is now ready to program the FX
plugged into Port 2 of the HUB.
• 1-2ph Master is the factory default value for
each FX.
ADV/FX/STACK----------P02
stack Classic Slave
phase
DOWN INC DEC PORT
Pressing the soft key will keep the MATE’s
attention on Port 2, but will change the stack
phase to Classic Slave screen. Port 02 will then be
assigned as a Classic Slave.
You can change the stacking phase by pressing
the or soft keys and change to
a diff erent Port by continuously pushing the
soft key.
NOTE: There are no or commands in the stacking menu. Whichever value—Master or
Slave—shows up on the MATE screen will be assigned to the chosen Port (and FX) upon leaving that
screen. It’s important to watch the Port number in the top right corner of each screen to be sure you’ve
assigned it the desired status.
Systems with two to ten FXs call for OutBack
Slave Stacking. Press the soft key in the
ADV/FX/STACK screen to change the stack phase
from Classic Slave to OB Slave L1.
ADV/FX/STACK-----------P02
stack Classic Slave
phase
DOWN INC DEC PORT
OUTBACK (OB) SLAVE
