With the programming completed,
turn the AC output breakers ON
with the AC BYPASS on the AC
breaker panel switched to NORMAL.

Verify the AC voltage output through the MATE following path:

PATH

MAIN---------------------

SETUP------------

STATUS/FX/PAGE1---------- Float P00

STATUS/FX/METER—P00

12.15:30p

choose device:

choose category:

inv 0.0Kw zer 0.0kw

output 230 vac

chg 0.0kw buy 0.0kw

voltage

SUM STATUS SETUP ADV FX CC DC MAIN

MODES METER BATT PG2

DOWN STATUS PORT

DOWN UP TOP PORT

POWERING UP
