Charger menu – Outback Power Systems VFX Series International Programming Manual User Manual
Page 14

13
ADV
choose device:
FX
CC DC MATE
ADV/FX/PAGE 1-----------------
choose category:
ADV INV CHGR PG2
ADV/FX/CHARGER---------P00
charger
7.0 aac
limit
DOWN INC DEC PORT
ADV/FX/CHARGER---------P00
absorb
14.4 vdc
set point
DOWN INC DEC PORT
CHARGER MENU
Each battery manufacturer has specifi c recharging directions and guidelines. OutBack’s default values
work for many batteries, but might not be the ideal settings. The CHARGER Menu allows these settings
to be adjusted. Please refer to your manufacturer’s recommendations.
From the ADVANCED menu, press
.
Press
.
The charger limit is the maximum AC current the
FX uses to charge the batteries. Depending on
the FX model, the setting range is as low as
0.0 AAC to between 6.0AAC and 10.0AAC
using and
. Press
to continue in the CHARGER Menu.
The absorb set point is the fi rst stage (BULK)
recharging voltage for the batteries. This set point
ranges from 13.0VDC to 16.0VDC as determined
using and
. Press
to view
the absorb time limit screen.
FX
CHGR
INC
DEC
DOWN
INC
DEC
DOWN
