30

ADV/FX/STACK----------P02

stack OB Slave L1

phase

DOWN INC DEC PORT

OUTBACK (OB) SLAVE L2

• Set the FXs you want as series slaves (Leg 2) to OB Slave L2.

• This FX is considered the L2 phase.

To use OutBack Slave L2 Stacking, press the

soft key in the ADV/FX/STACK OB screen

to change the stack phase from OB Slave L1 to OB

Slave L2.

ADV/FX/STACK----------P02

stack OB Slave L1

phase

DOWN INC DEC PORT

ADV/FX/STACK----------P02

stack OB Slave L2

phase

DOWN INC DEC PORT

The FX assigned to Port 02 now has OB Slave L2
status.

ADV/FX/STACK-----------P01

stack 1-2 ph Master

phase

DOWN INC DEC PORT

A 3-phase system with only three FXs requires

one of two diff erent stacking procedures. Starting

from the fi rst stacking menu—ADV/FX/STACK—

press the soft key four times.

Press four times

3-PHASE (3PH) MASTER

OB Slave 1 stacking phase
