ADV/FX/AUX--------------P00

genalert 9 min

off delay

DOWN INC DEC PORT

After a battery has recharged or returned to

the genalert off set point, genalert off delay

determines the amount of time the generator

remains on to assure the battery has been more

fully recharged. The user can adjust this time

from 0-240 minutes in using the and

soft keys. Press the soft key to view the

loadshed off set point screen.

ADV/FX/AUX---------------P00

loadshed 11.0 vdc

off set point

DOWN INC DEC PORT

The loadshed off set point is the battery voltage

which triggers the AUX to reduce the inverter

and battery loads. When the battery voltage

drops below this value for three seconds, the

AUX powers a DC coil relay to disconnect an AC

load. Once triggered, loadshed remains on for at

least three minutes. The loadshed off set point

is adjustable from10 VDC-14VDC using the and

soft keys. Press the soft key to bring

up the ventfan on set point.

ADV/FX/AUX--------------P00

ventfan 13.0 vdc

on set point

DOWN INC DEC PORT

Recharging causes batteries to emit mostly hydrogen

gas. When the AUX is set to ventfan, a fan ventilates

a battery enclosure. The ventfan on set point establishes

the battery voltage which energizes the AUX and thus

the fan for a one minute period. The voltage setting has

a range of 10.0VDC-16.0VDC in 0.1 VDC increments

using the and soft keys. Press the

soft key to view the ventfan off period screen.

ADV/FX/AUX--------------P00

ventfan off 5 min

period

DOWN INC DEC PORT

If a ventilation fan is only needed intermittently,

the ventfan off period shuts the fan off for a user-

determined time before starting up again for a one-

minute period when the battery voltage exceeds the

ventfan on set point. This off period can be set from

0-30 minutes using the and soft keys.

Setting this period to zero will keep the fan running

the entire time the battery voltage is high enough to

activate the ventfan function. Setting it to fi ve minutes

means the fan will run for one minute and then shut

off for fi ve minutes until the battery voltage drops and

the fan is no longer needed. Press the soft

key to view the diversion on set point screen.
