Wireless Repeater

Mounting the Repeater

Once you determine that your chosen location transmits and receives the sig-
nal, continue with the installation by mounting the repeater. Mounting hard-
ware has been included for the most common installations (see figure on page
9 for instructions).

CAUTION: Any prominent object, including an outside-mounted
repeater, can attract a lightning strike. If lightning strikes your unit or

strikes somewhere nearby, the unit’s internal electronics may suffer. The unit
itself has been designed with considerable surge protection, but to safeguard
nearby equipment and structures, we recommend following local recommen-
dations on properly grounding your installation. For more information, contact
your local lightning protection authority and/or refer to the following articles:

MIL-HDBK-419A: Grounding, Bonding, and Shielding for Electronic Equipments
and Facilities,
29 Dec 1987.

National Fire Protection Association, 1997: Standard for Installation of Lightning
Protection Systems,
1997 ANSI/NFPA 780, National Fire Protection Association,
Quincy, MA.

NEC, National Electrical Code, 1996 Edition: National Fire Protection Information,
Quincy, MA.

Mounting the Repeater

Mounting the AC-Powered Repeater

1. Choose a location with access to AC power.

2. Mount the shelter against a wall or post, or on a pipe.

See page 9 for figures showing wall or post and pipe mounts.
