Sp e c i f i c a t i o n s

Operating Temperature . . . . . . . . . . . . . . . . . . . . . . +14° to +140°F (-10° to +60°C)

Non-operating Temperature . . . . . . . . . . . . . . . . . . -5° to +158°F (-20° to +70°C)

Current Draw, Cabled . . . . . . . . . . . . . . . . . . . . . . 10 mA average, 15 mA peak at 4 to 6 VDC
Current Draw, Wireless . . . . . . . . . . . . . . . . . . . . . 0.77 mA average, 15 mA peak, (plus .125 mA for

each optional wireless transmitter in use) at 4 to 6
VDC

AC Power Adapter . . . . . . . . . . . . . . . . . . . . . . . . . 5 VDC, 200 mA, regulated
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 AA-cells

Battery Life, Cabled . . . . . . . . . . . . . . . . . . . . . . . . up to 10 days

Battery Life, Wireless . . . . . . . . . . . . . . . . . . . . . . . up to 5 months
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Modular RJ-11

Cable Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-conductor, 26 AWG

Housing Material. . . . . . . . . . . . . . . . . . . . . . . . . . . ABS plastic
Dimensions

Cabled. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.375" x 3.7" x 1.375" (162 mm x 94 mm x 35 mm)
Wireless (includes antenna) . . . . . . . . . . . . . . 6.375" x 4.35" x 1.375" (162 mm x 111 mm x 35 mm)

Weight (with batteries) . . . . . . . . . . . . . . . . . . . . . . 0.58 lbs. (0.26 kg)
