Fan-Aspirated Radiation Shield
Installing the Sensor Board
Here’s how to install the sensor board supplied with the radiation shield:
1.
Insert the board into the grooves in the sensor chamber walls.
2.
Push the cable gently into the sensor chamber, allowing the cable to loop a
little.
3.
Route the cable to the cable channel.
Core Unit
Sensor
Chamber
Cable
Channel
Temp/Humidity
Sensor Board
with
Sensor Cover
Temp Probe
mounted on
Sensor Board
OR
Installing the Sensor Board
