PowerTap Pro - Manual (Page 10)

10
General Operation of Computer
The Powertap has three main displays: power
display (top), speed display (middle), and multi-
function display (bottom). There are two main
modes of operation in the Powertap: trip mode and
interval mode.
Mode Button (Left)
Press the mode button to scroll between the
different displays. The active display is indicated by
small black triangles at the left and right side of the
display. Hold the mode button down for two sec-
onds to toggle between trip and interval modes. The
"INT" icon will illuminate when you enter interval
mode.
Select Button (Right)
Press the select button to select which function is
shown on the current display. The current function
will remain on the display even when the mode but-
ton is used to move to another display. The select
button also starts, stops and indexes intervals in
interval mode.
Menu (Both Buttons)
To enter the set up main menu hold down both buttons
until the main menu is displayed
Press select to choose the desired set
up and press mode to begin set up.
E = exit, return to ride mode
d = restore default settings
T= Test Mode
Power Conservation
The computer and hub have power saving features
to prolong battery life. The computer powers down
the display after 4 minutes of inactivity. Press one of
the buttons to activate the display. Similarly, the hub
powers down after two minutes of inactivity. The
transmission icon will not be visible when the hub is Figure 7: Powertap button and display summary
TRANS.
ICON
INTERVAL
DISPLAY
MODE (LEFT)
POWER
DISPLAY
SPEED
DISPLAY
MULTI
DISPLAY
BOTH SELECT (RIGHT)
Changes active
mode
Clear data
Enter setup
Select function
Starts/stops/index
intervals
POWERTAP STANDARD COMPUTER GENERAL OPERATION
Set
E
1
t
d
Main Menu
asleep. Spin the wheel momentarily and the icon will
illuminate.
