Installation 71
In
st
al
la
ti
o
n
Step 4: Install BCCs
The disk system comes with one or two BCCs, depending on the option
purchased. If you are installing only one BCC, you will install a BCC filler in the
open BCC slot.
1. Attach your ESD strap to ground.
2. Unpack the BCC from the accessories box and ESD bag.
WARNING Do not touch the pins on the back of the BCC.
3. Loosen the locking screws (D in Figure 41 ) if necessary on the BCC
cam latches.
4. Open the BCC cam latches (C in Figure 41 ) by pulling them away
from the center.
5. Align the BCC alignment guides (E) with the slot, and insert the BCC
into the the left slot at the back of the disk system. Stop pushing when
the BCC meets the midplane.
6. Press the cam latches inward and flat against the center. The cam action
draws the BCC completely into the slot and seats the connector pins
on the midplane.
7. Tighten the locking screw (D).
