HP StorageWorks 2300 Disk System - Manual (Page 138)

138 Removal and Replacement
Reinstalling the deskside base and external covers on the disk
system.
1 Place the deskside external cover on its top, on a sturdy surface.
2 Lift the disk system chassis into the cover, onto the alignment pins. The disk
system should be installed into the cover with the power switch down (toward
the closed part of the cover).
3 Secure the base to the cover using four M5 screws. Tighten the screws using a
Torx T25 driver. They are the four screws that are closest to the edges of the
base.
4 Secure the base to the chassis using four M5 screws. Tighten the screws using
a Torx T25 driver. They are the four screws that are closest to the edges of the
base.
