HP StorageWorks 2300 Disk System User Manual
Page 116

116
Removal and Replacement
empty slot will cause uneven cooling and eventual overheating.
1
Release the disk from the slot by squeezing the latch tab (B) and pulling it
toward you.
Caution
Spinning disks generate heat and gyroscopic force.
Wait for a spinning disk to slow down and cool off
before removing it from the product.
WARNING
High current available. Avoid touching the midplane or adjacent
drive electronics when removing and inserting disk modules.
2
Pull the disk out of the slot, using the latch until you can get your hand around
the handle (C). Support the disk module with your other hand around the
enclosed side.
Note
Removing disk modules and fillers from right to left improves
access to successive disk modules.
