WWN of Port Controller Model
XXXXXXXXXXXXXXX4 Controller 1
XXXXXXXXXXXXXXX5
XXXXXXXXXXXXXXX6
XXXXXXXXXXXXXXX7
Note: In WWNs, "X" is an arbitrary number or character. The ports in the same physical storage system have the
identical value.
HUS/AMS/WMS
The table below shows the system parameters that must be specified for ports on HUS, AMS, and
WMS storage systems when used with External Storage. You can specify or omit any other
parameters.
Also, ensure the following two settings using Storage Navigator Modular or Storage Navigator
Modular2:
•
Set the data transfer speed of the external port to a fixed value other than Auto.
•
Set the data transfer speed of the target port of the HUS/AMS/WMS storage system to a
fixed value consistent with the data transfer speed of the external port.
Parameter Settings Parameters Window Names
Start Attribute Boot Options
Specify when HUS/AMS/WMS is in a one-controller
configuration. Single Mode
Specify when HUS/AMS/WMS is a two-controller
configuration. Dual Active Mode
Optional Delay Planned Shutdown
Optional Drive blocking mode
HITACHI (default-do not change) Vendor ID
DF600F (default-do not change) Product ID
Optional ROM Microprogram Version
Optional RAM Microprogram Version
Optional Option System Parameter
Reset of occurred. Operation if the processor failure
occurs
Optional WEB Title
For AMS 1000, AMS 500, AMS 200 and WMS 100:
ON Write and verify mode
For HUS 150, HUS 130, HUS 110, AMS 2500, AMS
2300, AMS 2100, and AMS 2010: OFF
Optional Port Option Port Options
Set AMS common setting to Standard Mode. Host Connection Mode 1 Host Connection
Mode
Do not specify any parameters for AMS additional
settings. Host Connection Mode 2
For AMS 1000, AMS 500, AMS 200 and WMS 100,
do not specify HISUP OFF mode.
HUS/AMS/WMS 83
