Parameter Settings Parameters Window Names
ON Command Queuing Mode Inquiry Setting
HITACHI (default) Vendor ID
DF600F (default) Product ID
Optional ROM Microprogram Version
Optional RAM Microprogram Version
Optional WEB Title
Reset/LIP Mode Port Type
Optional Reset/LIP Mode (Signal)
Optional. Reset/LIP Mode (Process)
Optional LIP Reset Mode
Optional RS232C Error Information Outflow
Mode Controller Option
ON Write and verify mode
Standard Mode Host Connection Mode 1 Host Connection Mode
HISUP Mode (do not specify any other parameter). Host Connection Mode 2
Identifying the 9500 V model using the serial number
You can identify the storage system model from the serial number displayed in the Vendor / Model
/ Serial Number column in the External Storage System tab.
The following table shows the relationship between the number in the Serial Number column and
the storage system model.
Model Displayed Serial Number
9570V, 9520V D600XXXX
9530V D60JXXXX
9580V, 9585V D60HXXXX
Note: In serial numbers, "X" is an arbitrary number or character.
Identifying the controller using the port WWN
You can identify the controller (controller 0 or controller 1) from the WWN of the port.
The following table describes the relationship between the port WWN and the controller.
WWN of Port Controller Model
XXXXXXXXXXXXXXX0 Controller 0 9570V
XXXXXXXXXXXXXXX1 9530V
9520V
XXXXXXXXXXXXXXX2 Controller 1
XXXXXXXXXXXXXXX3
XXXXXXXXXXXXXXX0 Controller 0 9580V
XXXXXXXXXXXXXXX1 9585V
XXXXXXXXXXXXXXX2
XXXXXXXXXXXXXXX3
82 Supported external storage systems
