Page 104
Description
Item
When clicked, launches the Edit External Path Configuration window.
Edit External Path Configuration
When clicked, launches the Edit Policies window.
Edit Policies
When clicked, allows you to save table information to a file.
Export
Selected external path group window
Use this window to view the mapped external volumes using the external path, and view the
external paths in the path group.
You can perform these operations from the window.
•
“Mapping an external volume” (page 34)
•
Edit Cache Mode and Inflow Control settings for individual mapped volumes (see
)
•
View path status and external LUN information (see the Status description in the
section.)
•
“Deleting an external volume mapping ” (page 62)
•
“Disconnecting a single mapped volume ” (page 57)
•
“Reconnecting a single mapped volume ” (page 61)
•
“Changing external volume MP blade ” (page 44)
•
“Editing external volume policies (settings)” (page 42)
•
Export table information to a file (see the Export button description in
section.)
Information areas in this window:
•
•
•
Summary
Displays summary information about the selected external path group.
Description
Item
Status of path groups.
Status
•
Normal: There are no problems, the path group is usable.
•
Disconnect: The path group has been intentionally disconnected.
•
Checking: The system is checking the mapping path status.
•
Unknown: The status of the mapping path is not known.
•
Cache Destage: The writing of data from cache memory to the external volume
is in progress.
•
Warning: There are mapping paths whose status is not normal. You can check
their status in the View External LUN Properties window.
•
Blockade: The mapping path is blocked.
•
Destage Failed: The writing of data from cache memory to the volume is
failed.
Identifying information for the external system.
Vendor / Model / Serial Number
Number of external paths in the external path group.
Number of External Paths
104 External Storage GUI reference
