Starting the Repository Editor Using appletviewer
To start the editor using the JavaSoft appletviewer:
Set the CLASSPATH to include the Jolt class directory. 1.
If loading the applet from a local disk, type the following at the URL location:
appletviewer /RE.html
If loading the applet from the Web server, type the following at the URL location:
appletviewer http:////RE.html
2.
Press Enter. The Repository Editor logon window displays. 3.
Starting the Repository Editor Using Your Web Browser
To start the Repository Editor from a local file:
Set the CLASSPATH to include the Jolt class directory. 1.
Type the following:
file:/RE.html
2.
To start the Repository Editor from a Web server:
Ensure that the CLASSPATH does not include the Jolt class directory 1.
Unset the CLASSPATH. 2.
Type the following:
http:////RE.html
Note
Before opening the file, modify the applet codebase parameter in RE.html to match your Jolt Java classes directory.
3.
Press Enter. The Repository Editor logon window displays. 4.
Logging on to the Repository Editor
After starting the Jolt Repository Editor, follow the directions to log on:
Type the name of the server machine designated as the "access point" to the TUXEDO application and select the port number
text field. 1.
Type the port number and press Enter. The system validates the server and port information.
Note
Unless you are logging on through the Jolt Relay, the same port number is used to configure the Jolt Listener. Refer to your
UBBCONFIG file for additional information.
2.
Type the TUXEDO Application Password and press Enter. Based on the authentication level, type the remaining information. 3.
Type the TUXEDO user name and press Tab. 4.
Type the TUXEDO user password and press Enter.
Note
The Jolt 1.1 Repository Editor uses the hardcoded joltadmin for the user role. See the
JoltSessionClass for additional information.
5.
