Menu item
Sub-menu item
Sub-menu item
Values and Description
Depending on the execution time, a selected test
runs continuously until either the device is turned off,
or an error occurs and a diagnostic page is printed.
LAN HW Test
CAUTION
Running this embedded test will
erase your TCP/IP configuration.
This test performs an internal loopback test. An
internal loopback test will send and receive packets
only on the internal network hardware. There are no
external transmissions on your network.
Select
Yes
to choose this test, or
No
to not choose it.
HTTP Test
This test checks operation of HTTP by retrieving
predefined pages from the device, and tests the
embedded Web server.
Select
Yes
to choose this test, or
No
to not choose it.
SNMP Test
This test checks operation of SNMP communications
by accessing predefined SNMP objects on the device.
Select
Yes
to choose this test, or
No
to not choose it.
Select All Tests
Use this item to select all available embedded tests.
Select
Yes
to choose all tests. Select
No
to select
individual tests.
Data Path Test
This test helps to identify data path and corruption
problems on an HP postscript level 3 emulation
device. It sends a predefined PS file to the device,
However, the test is paperless; the file will not print.
Select
Yes
to choose this test, or
No
to not choose it.
Execution Time [H]
Use this item to specify the length of time (in hours)
that an embedded test will be run. You can select a
value from 1 to 60 hours. If you select zero (0), the
test runs indefinitely until an error occurs or device is
turned off.
Data gathered from the HTTP, SNMP, and Data
Path tests is printed after the tests have completed.
Execute
No
*: Do not initiate the selected tests.
Yes
: Initiate the selected tests.
Table 2-10
Jetdirect menus (continued)
