Switch-to-Switch PIC
that connects to another switch on the same
fabric. The last part of the name contains the port number where the PIC is located. Only the
PICs in ports 8 through 11 of the switch are used for switch-to-switch connections.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
> Switch PIC
Example: Switch PIC $ZZSMN.Y3.10 (indicates the PIC in port 10 of switch Y3)
Attributes
Switch PIC
Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or
service is required.
Logical
Connectivity Status
The state of connectivity between the switch and the node to which this
PIC connects.
Values:
Connected
Not Connected
Connected to Switch With Wrong Fabric
Connected to Node
Connected to Wrong Port
Connected to Different Switch
Connected to Switch With Wrong Configuration
Unknown
Presence
Whether the PIC is installed and responding.
Values: Present, Absent, Unknown
Neighbor Switch PIC
PIC Name
The neighbor switch and PIC to which this PIC is connected.
Example: Switch PIC $ZZSMN.X.1.8 (indicates that this PIC is connected to
switch X1, PIC 8)
