Service State
Displayed in the Attributes tab and Attributes dialog box only if attention or service is
required.
Values
Physical
Time Of Last Reset The date and time that the service processor was last reset.
Stored Topology
The maximum processor configuration for the service processor that is set
the next time the system or enclosure is powered on.
Values
Master SP
Whether this service processor is the master service processor on the
system:
True: This is the master service processor.
False: This is not the master service processor.
Running Image Source
Whether the SP firmware was loaded from its own, the peer's, or the backup
flash memory.
Values: ???, Running From Local Flash
IP Address The IP address of the service processor.
Current Topology The maximum processor configuration for the service processor. Values
Device State
The state of the service processor:
Active (Primary): This is the master service processor and is available.
Active (Secondary): This is the not master service processor, but it is
available.
Firmware Update Mode: An SP firmware update is in progress.
In Test: Temporary state during power-on self-test.
Initializing: Temporary state during startup.
SP Stopped Responding to Peer:
Fabric Side Values: X or Y
SP Firmware
Version The VPROC of the firmware currently loaded on the service processor.
Default File Name
The name of the file to be used for the service processor firmware update.
(SPCODE9)
Default File Version The version of the firmware to be used for a firmware update .
Compare State
The differences, if any, between the current and default firmware versions.
Values
SCSI Boot Code Firmware
