Component identification 12

The arrow points to the front of the workstation blade.

DIMM tool location

The DIMM tool is used to open and close an empty DIMM slot.

HP c-Class Blade SUV Cable

Item

Connector

Description

1

Server blade

For connecting to the SUV connector on the

workstation blade front panel
