ii 59273-00 C
H3C LSW1FC4P0 Interface Card for S5820X-28C Ethernet Switches
QuickTools User Guide
The information in this document is subject to change without notice. Every effort has been made in the preparation of
this document to ensure accuracy of the contents, but all statements, information, and recommendations in this
document do not constitute the warranty of any kind, express or implied.
This product is covered by one or more of the following patents: 6697359, 7,660,302, 7,542,676, 7,340,167,
7,573,909, 7,583,597, 7,580,354, 7,649,903, 7,613,816, 7,430,175, 7,525,983, 7,522,522, 7,447,224, 7,420,982,
7,512,067, 7,477,655, 7,630,384, 7,646,767, 7,558,281, 7,519,058, 7,525,968, 7,518,995, 7,548,560, 7,669,001,
7,684,398; other patents pending.
Document Revision History
Revision A, June, 2010
Revision B, September 2011
Revision C, July 2011
Changes Pages Affected
Updated for firmware version 9.0.7 Throughout
Added Security Consistency Checklist to menus 1-5 , 1-6
Added RequireEnodeMACConfig 2-28 , 2-14
Added IPV4 Gateway entry 2-15
Updated VLAN Manager Dialog 2-33
Updated FCF Configuration Manager Dialog 2-34
Updated Selective Restore Dialog 2-45
Updated Class 3 Toss entry 3-65
Updated Port Address entry 3-72
Replace Ethernet Port Statistics Data Window fig-
ure 3-68
Updated DCBX Enabled and PFC Priority entries 3-73
Removed references to E_Ports and E_Port status Table 3-17 , Table 3-18
