Using QuickTools
Opening QuickTools
2 59273-00 C
Opening QuickTools
After the H3C LSW1FC4P0 Interface Card is operational, open QuickTools by
entering the H3C LSW1FC4P0 Interface Card IP address in an Internet browser. If
your workstation does not have the Java 2 Run Time Environment program, you
will be prompted to download it. The Login to Switch dialog (
Figure 1-1 ) prompts
you for your username and password. Leave NAT mode unchecked unless there
is a router between the management workstation and the H3C LSW1FC4P0
Interface Card that is configured with network address translation (NAT). Click the
Add Fabric button to open the fabric.
Figure 1-1. Login to Switch Dialog
The opening window is displayed ( Figure 1-3 ). For security reasons, you will be
prompted to change your user account password that was initially set up by the
administrator (
Figure 1-2 ). You will be prompted to change the password each
time you attempt to open the fabric until you change the default password. Click
the OK button, and change the user account password. Refer to
”Managing User
Accounts” on page 2-18 for more information.
Internet Browser
(to view online help
 Microsoft® Internet Explorer® 6.0 and later
 Netscape® Navigator® 6.0 and later
 Firefox® 1.5 and later
 Safari® 1.0 on Windows OS
 Java 2 Standard Edition Runtime Environment 1.4.2 to support
the web applet
Table 1-1. Workstation Requirements
