HP Designjet 4500 Printer series User Manual
Page 38
6.
Lift the supporting framework of the bin into position in front of the printer.
7.
Fix the top arms of the bin to the two screws that you have just fitted.
8.
Fix the lower arms of the bin to the stand using one screw for each leg.
9.
Now tighten the two top screws.
10. Clip all six loops to the frame of the bin. Locate the loops with rear extensions in positions 2, 4,
and 6.
24
Chapter 2 How do I... (printer assembly topics) [4000]
ENWW
How do I... (printer
assembly topics) [4000]
