Description
Item
If you selected a P-VOL, the serial number of the RCU (secondary system) and the SSID or
Path group ID display. If you selected an S-VOL, MCU (primary system) information displays.
RCU (or MCU) S/N and
ID
Controller ID and model name of the secondary system.
Controller ID
•
For controller ID 6, P9500 is the model name.
•
For controller ID 5, XP24000/XP20000 Disk Array is the model name.
•
For controller ID 4, XP12000 Disk Array/XP10000 Disk Array is the model name.
Data path channel type.
MCU-RCU Path
Pair type: (Cnt Ac-S) Synchronous, Synchronous-C, Multi-C, or ESAM.
Update Type
Number of tracks copied per interval during the initial copy. Copy pace can be between
1-15 tracks.
Copy Pace
This field displays only when the P-VOL is selected. It is disabled when the status becomes
PAIR.
Order in which initial copy/resynchronizing operations are performed on multiple pairs.
Initial Copy Priority
This field displays only when the P-VOL is selected. It is disabled when the status becomes
PAIR.
The P-VOL shows Never, Data, or Status. For more information, see
for I/O to the P-VOL after suspension” (page 21)
.
P-VOL Fence Level
Indicates whether write I/O to the S-VOL is enabled or disabled. When Enabled,
“Enabled/Received” or “Enabled(Not Received” appears depending on whether I/O has
been received by the volume.
S-VOL Write
Date and time the pair was created.
Paired Time
Date and time pair status was last updated.
Last Update Time
Amount of time for the actual pair creation to complete. This differs from the time displayed
in the Copy Time field on the History window, which includes the extra time used by the
storage system to receive the request and start the operation.
Pair Copy Time
This field displays only when the P-VOL is selected.
Method by which differential data is stored: by cylinder or by track.
Difference Management
Quorum disk ID assigned to the ESAM pair.
Quorum Disk ID
Access status of the ESAM volume.
VOL Access
Consistency group number for a Synchronous-C or Multi-C pair.
Sync CT Group
When the consistency group number is bracketed [1], the consistency group consists of
multiple and secondary XP P9500s.
The status of the preserve mirror when it is associated with Compatible FlashCopy. If PAIR
WAS THE TARGET OF A WITHDRAWN PM RELATIONS displays, the data of the pair
volumes does not synchronize despite its pair status.
PM Status
If the box is checked, the Pair Operation window updates when the Detailed Information
dialog box closes.
Refresh the Pair Operation
window after this window
is closed:
Paircreate(Synchronous) dialog box
Use this dialog box to create a pair.
See
for complete information.
Paircreate(Synchronous) dialog box
