Description Item
Displays the connected storage system, LDKC, CU grouping, CUs, ports, and host groups.
Select the desired CU grouping, CU ( ), port ( ), or host group to display related LUs.
Only one CU grouping, CU, port, or host group can be selected.
Tree
Note: Though LDKC#01 displays in the Tree on some Cnt Ac-S windows, it is not available
for use in this version.
Lists and allows you to review your current operations not yet applied to the storage system.
You can change or delete the operations when you right-click the item in the Preview list.
Clicking Apply commits them to the system. Preview List
Opens the Display Filter dialog box, which allows you to control the volumes that display in
the list. See
“Display Filter dialog box ” (page 103) .
Display Filter
Used to export status information for the LU to a text file. Export
Each row shows volume information. If it is also a pair volume (other than SMPL status), pair
information also displays. The list can be sorted by column. For LUs with more than one path, Volume list
each path displays in a separate row. For the selected item (storage system or CU), displays
the detailed LVI information. If a CU grouping or a CU is selected from the tree, only one
path displays for one LU on the list.
Pair Operation window 95
