ServerNet Switch Board
A component of the
, the ServerNet Switch Board provides ServerNet connectivity between
processors, ServerNet adapters, and attached hardware devices.
OSM software communicates with an internal part of the switch known as the Maintenance Entity
(ME) by a connection established through the
.
Location in OSM Tree:
In an IOAM: System > Group > IOAM Enclosure > IOAM > ServerNet Switch Board
Example: ServerNet Switch Board (11.2.14)
Attributes
ServerNet Switch Board
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Physical
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
LED State
Indicates whether the ServerNet Switch Board LED is on or off.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Logical
Time of Last Reset The date and time of the last soft reset of the ServerNet Switch Board.
ME FPGA
Version
The VPROC of the ME FPGA (Field Programmable Gate Array) image
currently loaded on the switch logic board.
Default File Name
The full path name of the default ME FPGA file on the server.
Default File Version The version of the ME FPGA image in the default FPGA file.
Compare State
The differences, if any, between the current and default ME FPGA versions.
