Page 155: A component of
Example: PMCU (1.1.21)
Attributes
PMCU
Service State
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Physical
Power State
Whether the component is powered on.
Part Number
The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.
Track ID
A unique serial number that identifies the component. Track IDs are used for
tracking components.
Hardware Revision
A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.
Temperature Sensor
Normal Minimum Value
The minimum acceptable air intake temperature is 5 degrees Celsius. If
the temperature falls below 5 degrees, an alarm is generated.
Current Value
The current temperature, in degrees Celsius (°C), inside the enclosure of
the module.
Normal Maximum Value
The maximum acceptable air intake temperature is 50 degrees Celsius. If
the temperature rises above 50 degrees, an alarm is generated.
Actions
None.
PMF (Processor Multifunction)
Each processor multifunction (PMF) CRU in a NonStop server contains these components:
A processor and memory board (PMB), which contains a
●
(S7000 only)
●
●
Three
●
