Operating the Tape Drive
5158ACL Tape Drive Installation and User’s Guide — 524955-002
3- 10
Entering the Menu Mode
Entering the Menu Mode
When the Default screen appears, enter the menu mode by pressing Enter. The
Main menu shown appears. See
Figure 3-7 .
When you press Enter, the screen in Figure 3-9 appears.
Note. When you press Enter to enter the menu mode, the Ready light goes out, indicating that
the tape drive is offline. The tape drive responds to all SCSI commands from the server by
reporting “Not Ready” until you exit the menu mode and the Ready light goes on.
To prevent inadvertent interruption of server operations, the menu mode can be locked by
using the Security menu. See
Figure 3-14, Security Menu . When the control panel is locked,
you must enter the unlock code to display the Main menu. The Show Status menu remains
accessible and can be displayed from the Default screen at any time by pressing Escape.
Figure 3-7. Main Menu
Note. If the Control Panel is locked, the screen shown in Figure 3-8 appears. You need the
unlock code for the specific tape drive before proceeding. If you do not know the code, contact
the server administrator.
Figure 3-8. Panel Locked Screen
Figure 3-9. Code Entry Menu
