100

Troubleshooting

Interpreting Status Values

SAM and STM report status in common terms, which are defined as follows:

Enclosure ID

The unique manufacturer number that
distinguishes the reporting LCC from all other
LCCs.

WW Name (node)

The World Wide Name assigned to this disk
system. In normal operation, this value is the same
as the World Wide Name (port) for LCC A.

WW Name (port)

The World Wide Name of the reporting LCC.

Firmware Rev.

The current firmware version on the reporting
LCC.

Power Supply Status

The status of the left (Supply A) and right (Supply
B) power supplies in the selected disk system.
Possible values are OK, critical, not installed, or
not available.

Voltage Sensors
Voltage and Status

The voltage detected and status of three voltage
sensors—3.3V, 5.0V, and 12V—on each LCC.
Possible status values are OK, critical, noncritical,
not installed, unknown, and not available.

Temp Sensors
Temperature and Status

The temperature detected and status of four
sensors. Possible status values are OK, critical,
noncritical, not installed, unknown, or not
available.

Table 12.

Status Indications

Reported

Status

Applicable

Component

Indication

OK

All replaceable
components and
sensors

Component is installed and no error
conditions are known.
