Part Names
42
Side Control
LED indicators
The projector status is shown by the LED indicators (off / lit / flashing).
For indicator status, refer to “LED Indicator Displays” (
P43 ).
(1) POWER button ( P52 , P74 )
Turns the projector on or off.
(2) INPUT button ( P54 )
Switches the input signal.
(3) AUTO PC button ( P57 )
Adjusts tracking etc. automatically
in accordance with the signal from
a computer when the analog PC
input is selected.
(4) KEYSTONE button ( P68 )
Corrects keystone distortion.
(5) Pointer / VOL buttons ( P77 , P85 )
Adjust the sound volume.
[ ] VOL+ button: Increases the
volume.
[ ] VOL– button: Decreases the
volume.
Selects the upper, lower, left or
right item in the menu.
(6) OK button ( P85 )
Determines the item selected from
the menu.
(7) MENU button ( P84 )
Displays a menu on the screen.
(1) (2) (3) (4)
(6)
(5) (7)
