6 Data transmission
33
6.4.6 Second and third setpoint (SW2/3)
With the SK 500E, the assignment of setpoints 2 and 3 to the process data words PZD3 and PZD4 is carried
out in the opposite manner to the SK 300E/700E/750E series.
6.4.6.1 Second and third setpoint SK 300E/SK 700E/SK 750E(SW2/3)
If the PPO type 2 or 4 is used, in addition to setpoint 1, a 2nd setpoint can be transferred in word PZD4 and a
3rd setpoint in PZD3.
PZD1 PZD2 PZD3 PZD4
STW SW1 SW3 SW2
A third setpoint value can only be transferred if a 32 Bit setpoint value is not transferred in the first setpoint.
PZD1 PZD2 PZD3 PZD4
STW SW1 SW2
The second and third setpoints are always 16 Bit. The function of the second and third setpoints can be set in
the inverter with parameter P547 ‘'Setpoint function 2’ and P548 ‘'Setpoint function 3’ respectively.
Both setpoints are transferred as whole numbers in the range (-32768 to 32767). The value 16384 (4000 HEX)
corresponds to 100%. The value C000 HEX is equal to –100%, so setpoints in the range
–200% to +200% can be transferred. A setpoint of 100% corresponds to the respective nominal value:
Setting 100% is equal to
Off
Setpoint frequency, actual frequency PID, actual
frequency PID limited, actual frequency PID monitored,
frequency addition, frequency subtraction, maximum
frequency Maximum frequency (P105)
Torque current limit Torque current limit (P112)
Current limit Inverter nominal current
Servo mode torque Nominal torque (P112)
Lead torque Lead torque (P214)
In addition, PosiCon control bits can be transferred here (see setpoint 1)
